  • FDA Food Grade High Transparent Heat Resistant Transparent Silicone Rubber Tube

    FDA Food Grade High Transparent Heat Resistant Transparent Silicone Rubber Tube



    Features

    1.Temperature range:-60ºC +200ºC

    2. It has been specially  processed, no poison and no smell, flaming resistance, good heatproof,aging resistance, it can bear 200ºC high temperature, high voltage and cook for many times.

    3. It is slick surface, soft and flexible

    4.It applies to the pipe of drinking water system, the heat insulation and insulation of electricity,Adopt high quality     material,can be processed tube, it be produced according of the standard of medical treatment.

    5. It is harmless to health, softness, non-toxic,water-fast, odorlessness, durable

    Main Parameters of Silicone Rubber Hose
      Type Specification ID (mm) OD (mm) Thickness (mm)
    Specially
    thin specification
    Φ 0.4/Φ2.3 Φ 0.4 Φ 2.3 0.950
    Φ 0.6/Φ2.3 Φ 0.6 Φ 2.3 0.850
    Φ 0.75/Φ2.3 Φ 0.75 Φ 2.3 0.775
    Φ 0.8/Φ2 Φ 0.8 Φ 2 0.600
    Φ 1/Φ3 Φ 1 Φ 3 1.000
    Ordinary specification Φ 1.8/Φ2.8 Φ 1.8 Φ 2.8 0.500
    Φ 2/Φ3 Φ 2 Φ 3 0.500
    Φ 3/Φ6 Φ 3 Φ 6 1.500
    Φ 4/Φ6 Φ 4 Φ 6 1.000
    Φ 5/Φ8 Φ 5 Φ 8 1.500
    Φ 6/Φ9 Φ 6 Φ 9 1.500
    Φ 6/Φ10 Φ 6 Φ 10 2.000
    Φ 7/Φ10 Φ 7 Φ 10 1.500
    Φ 8/Φ10 Φ 8 Φ 10 1.000
    Φ 8/Φ12 Φ 8 Φ 12 2.000
    Φ 9/Φ12 Φ 9 Φ 12 1.500
    Φ 10/Φ12 Φ 10 Φ 12 1.000
    Φ 10/Φ14 Φ 10 Φ 14 2.000
      Type Specification ID (mm) OD (mm) Thickness (mm)
    Big diameter Φ 12/Φ16 Φ 12 Φ 16 2.000
    Φ 14/Φ18 Φ 14 Φ 18 2.000
    Φ 15/Φ18 Φ 15 Φ 18 1.500
    Φ 16/Φ20 Φ 16 Φ 20 2.000
    Φ 18/Φ22 Φ 18 Φ 22 2.000
    Φ 20/Φ26 Φ 20 Φ 26 3.000
    Φ 26/Φ30 Φ 22 Φ 26 2.000
    Specially big diameter Φ 32/Φ38 Φ 22 Φ 28 3.000
    Φ 50/Φ60 Φ 50 Φ 60 5.000
    Φ 64/Φ72 Φ 64 Φ 72 4.000
    Φ 70/Φ80 Φ 70 Φ 80 5.000

    Food Grade Silicone Hose/Tube Specifications:

    Red industrial&food&medical grade silicon hose
    1.100% silicone material
    2. Any size/color is available
    3. CE FDA LFGB approval
    Food&medical grade silicon hose
